 The 2024 RAM 2500 HD pickup truck is built for work. And with its incredible capabilities comes an extraordinary stature. When not at work on Green Bay-area job sites, it's important to know this truck's overall size so you can maneuver and park it with ease. Continue reading to learn more about the 2024 RAM 2500 bed dimensions, overall 2024 RAM 2500 dimensions, and available RAM 2500 colors for the exterior in this guide from the RAM experts at Kolosso CDJR in Appleton!
2024 RAM 2500 Bed Dimensions
There are two bed options for the 2024 RAM 2500: a 6-foot, 4-inch box and an 8-foot box. Here are the RAM 2500 bed dimensions for both:Â
6-Foot, 4-Inch box (Crew or Mega)
- SAE volume: 57.5 cubic feet
- Length at floor: 76.3 inches
- Cargo width: 66.4 inches
- Distance between wheelhouses: 51.0 inches
- Depth: 20.1 inches
- Tailgate Opening Width: 60.4 inches
8-Foot box (Regular or Crew)
- SAE volume: 74.7 cubic feet
- Length at floor: 98.3 inches
- Cargo width: 66.4 inches
- Distance between wheelhouses: 51.0 inches
- Depth: 20.2 inches
- Tailgate Opening Width: 60.4 inches
As you can see, not every bed length is available with every cab choice. Although both bed lengths are available with the Crew Cab option, the shorter 6-foot, 4-inch box isn't available with the Regular Cab, while the 8-foot box isn't available with the Mega Cab.
2024 RAM 2500 Dimensions: Overall Exterior
The overall 2024 RAM 2500 dimensions vary based on the cab and bed combination, and in some cases, the trim level you can choose. Check out the overall RAM 2500 dimensions below:Â
Regular Cab + 8-Foot Box (4x2 / 4x4)
- Wheelbase: 140.2 inches
- Front Track Width: 68.7 inchesÂ
- Rear Track Width: 68.1 inches
- Length: 232 inchesÂ
- Width: 83.5 inches
- Height: 78.0 inches / 80.2 inches
- Front suspension or axle to ground: 7.3 inches / 9.3 inches
- Rear suspension or axle to ground: 8.4 inches / 8.5 inches
- Approach Angle: 18.8 degrees / 22.8 degrees
- Ramp Breakover Angle: 20.8 degrees / 23.9 degrees
- Departure Angle: 22.9 degrees / 29.9 degrees
- Ground Clearance: 13.0 inches / 13.1 inches
- Turning Diameter: 45.4 feet / 45.5 feet
Crew Cab + 6-Foot, 4-Inch Box (4x2 / 4x4)
- Wheelbase: 149.0 inchesÂ
- Front Track Width: 68.7 inchesÂ
- Rear Track Width: 68.1 inches
- Length: 238.8 inches
- Width: 83.5 inches
- Height: 78.2 inches / 80.2 inches
- Front suspension or axle to ground: 7.4 inches / 9.3 inches
- Rear suspension or axle to ground: 8.5 inches
- Approach Angle: 18.8 degrees / 22.9 degrees
- Ramp Breakover Angle: 20.3 degrees / 23.9 degrees
- Departure Angle: 23.6 degrees / 25.8 degrees
- Ground Clearance: 11.1 inches / 13.1 inches
- Turning Diameter: 47.9 feetÂ
Crew Cab + 8-Foot Box (4x2 / 4x4)
- Wheelbase: 169.0 inches
- Front Track Width: 68.7 inchesÂ
- Rear Track Width: 68.1 inches
- Length: 260.8 inchesÂ
- Width: 83.5 inches
- Height: 78.1 inches / 80.1 inches
- Front suspension or axle to ground: 7.3 inches / 9.4 inches
- Rear suspension or axle to ground: 9.9 inches / 8.6 inches
- Approach Angle: 18.7 degrees / 23.2 degrees
- Ramp Breakover Angle: 19.1 degrees / 22.7 degrees
- Departure Angle: 22.5 degrees / 24.7 degrees
- Ground Clearance: 11.1 inches / 13.1 inches
- Turning Diameter: 53.3 feetÂ
Power Wagon & Rebel Crew Cab + 6-Foot, 4-Inch Box (4x4 Only)
- Wheelbase: 149.3 inches
- Front Track Width: 68.7 inches
- Rear Track Width: 68.1 inches
- Length: 238.8 inches
- Width: 83.4 inches
- Height: 80.9 inches
- Front suspension or axle to ground: 8.3 inches
- Rear suspension or axle to ground: 8.3 inches
- Approach Angle: 29.4 degrees (Power Wagon) / 26.6 degrees (Rebel)
- Ramp Breakover Angle: 22 degrees (Power Wagon) / 21.8 degrees (Rebel)
- Departure Angle: 26 degrees
- Ground Clearance: 14.2 inches (Power Wagon) / 13.3 inches (Rebel)
- Turning Diameter: 48.2 feet
Mega Cab + 6-Foot, 4-Inch Box (4x4 Only)
- Wheelbase: 160.4 inches
- Front Track Width: 68.7 inches
- Rear Track Width: 68.1 inches
- Length: 249.9 inches
- Width: 83.5 inches
- Height: 80.1 inches
- Front suspension or axle to ground: 9.4 inches
- Rear suspension or axle to ground: 8.5 inches
- Approach Angle: 23.3 degrees
- Ramp Breakover Angle: 23.2 degrees
- Departure Angle: 25.7 degrees
- Ground Clearance: 13.1 inches
- Turning Diameter: 51.2 feet
2024 RAM 2500 Colors
Now that you know more about the size of the 2024 RAM 2500, it's time to see the wide array of RAM 2500 colors available for the exterior. Several of the RAM 2500 colors are exclusive to certain trim levels. See the 2024 RAM 2500 colors by trim level below:
Tradesman®, Big Horn®Â
Monotone Exterior Colors
- Diamond Black Crystal Pearl-Coat (available)
- Granite Crystal Metallic Clear-Coat (available)
- Billet Silver Metallic Clear-Coat (available)
- Patriot Blue Pearl Coat (available)
- Delmonico Red Pearl-Coat (available)
- Flame Red Clear-Coat
- Bright White Clear-Coat
Low Volume Exterior Colors (available)
- Black Clear-Coat
- Case IH Red
- Construction Yellow
- Detonator Yellow Clear-Coat
- Light Green
- Midnight Blue Pearl-Coat
- National Safety Yellow
- New Holland Blue
- Omaha Orange
- Republic Blue Clear-Coat
- School Bus Yellow
- Timberline Green Pearl-Coat
- Utility Orange
- YellowÂ
Laramie®
Monotone Exterior Colors
- Diamond Black Crystal Pearl-Coat (available)
- Granite Crystal Metallic Clear-Coat (available)
- Billet Silver Metallic Clear-Coat (available)
- Patriot Blue Pearl Coat (available)
- Delmonico Red Pearl-Coat (available)
- Flame Red Clear-Coat
- Bright White Clear-Coat
- Pearl White (available)
Rebel, Power Wagon®Â
Monotone Exterior Colors
- Diamond Black Crystal Pearl-Coat (available)
- Granite Crystal Metallic Clear-Coat (available)
- Billet Silver Metallic Clear-Coat (available)
- Patriot Blue Pearl Coat (available)
- Hydro Blue Pearl-Coat (available)
- Delmonico Red Pearl-Coat (available)
- Flame Red Clear-Coat
- Olive Green Pearl-Coat (available)
- Bright White Clear-Coat
Two-Tone Exterior Colors (Listed Color + Diamond Black Crystal Pearl Coat)
- Granite Crystal Metallic Clear-Coat
- Billet Silver Metallic Clear-Coat (available)
- Patriot Blue Pearl Coat (available)
- Hydro Blue Pearl-Coat (available)
- Delmonico Red Pearl-Coat (available)
- Flame Red Clear-Coat
- Olive Green Pearl-Coat (available)
- Bright White Clear-Coat
Limited Longhornâ„¢
Monotone Exterior Colors
- Diamond Black Crystal Pearl-Coat (available)
- Granite Crystal Metallic Clear-Coat (available)
- Billet Silver Metallic Clear-Coat (available)
- Patriot Blue Pearl Coat (available)
- Delmonico Red Pearl-Coat (available)
- Flame Red Clear-Coat
- Bright White Clear-Coat
- Pearl White (available)
Two Tone Exterior Colors (Listed Color + RV Match Walnut Brown Metallic Clear-Coat)
- Diamond Black Crystal Pearl-Coat (available)
- Billet Silver Metallic Clear-Coat (available)
- Bright White Clear-Coat
- Pearl White (available)
LimitedÂ
- Diamond Black Crystal Pearl-Coat (available)
- Granite Crystal Metallic Clear-Coat (available)
- Billet Silver Metallic Clear-Coat (available)
- Patriot Blue Pearl Coat (available)
- Delmonico Red Pearl-Coat (available)
- Bright White Clear-Coat
- Pearl White (available)
